Internal Reference:
HET1605933
Heater element
For Bags Etc flow wrappers and packaging machines
Part no. HET1605933
Quote it when you call or write
Confirm the fit
Send the machine model and serial number
Free UPS Ground shipping
On orders of $299 or more, US · ships from Santa Clarita, CA
Cartridge Heater - 0.23" Dia x 1.30" L (5.9mm x 33mm) - 60W - 110V - Stainless Steel Tube Heating Element
Replacement heating element for the seal stations of Bags Etc flow wrappers and packaging machines. Heater elements hold the seal blocks at a stable process temperature; replace a failed element with one of the same diameter, length, voltage and wattage.
Order online, or send us a photo of the part on your machine and we will match it for you.
Specifications
| Part number | HET1605933 |
|---|---|
| Diameter | 5.9 mm (0.23") |
| Length | 33 mm (1.30") |
| Power | 60 W |
| Voltage | 110 V |
| Sheath | Stainless steel tube |
| Ships from | Santa Clarita, CA |
Other heater elements
| Part | Part no. | Length | |
|---|---|---|---|
| 0.37" Dia x 12.2" L (9.3mm x 310mm) - 350W - 110V | HET135093310 | 310 mm (12.2") | 9.3 mm (0.37") · 350 W · 110 V |
| 0.37" Dia x 3.94" L (9.3mm x 100mm) - 250W - 110V | HET125093100 | 100 mm (3.94") | 9.3 mm (0.37") · 250 W · 110 V |
| 0.37" Dia x 3.94" L (9.4mm x 100mm) - 350W - 220V | HET235094100 | 100 mm (3.94") | 9.4 mm (0.37") · 350 W · 220 V |
| 0.37" Dia x 5.12" L (9.3mm x 130mm) - 250W - 110V | HET125093130 | 130 mm (5.12") | 9.3 mm (0.37") · 250 W · 110 V |
| 0.37" Dia x 6.10" L (9.4mm x 155mm) - 350W - 220V | HET235094155 | 155 mm (6.10") | 9.4 mm (0.37") · 350 W · 220 V |
| 0.37" Dia x 7.09" L (9.3mm x 180mm) - 300W - 110V | HET130093180 | 180 mm (7.09") | 9.3 mm (0.37") · 300 W · 110 V |
| 0.37" Dia x 7.09" L (9.4mm x 180mm) - 350W - 220V | HET235094180 | 180 mm (7.09") | 9.4 mm (0.37") · 350 W · 220 V |
| 0.37" Dia x 9.25" L (9.4mm x 235mm) - 350W - 220V - Stainless Steel Tube Heating Element | HET235094235 | 235 mm (9.25") | 9.4 mm (0.37") · 350 W · 220 V |
| 0.39" Dia x 11.42" L (9.8mm x 290mm) - 300W -110V | HET11030098290 | 290 mm (11.42") | 9.8 mm (0.39") · 300 W · 110 V |
| 0.39" Dia x 29.92" L (9.8mm x 760mm) - 900W - 220V | HET290098760 | 760 mm (29.92") | 9.8 mm (0.39") · 900 W · 220 V |
| 0.39" Dia x 5.75" L (9.8mm x 146mm) - 250W - 110V | HET125098146 | 146 mm (5.75") | 9.8 mm (0.39") · 250 W · 110 V |
| 0.39" Dia x 7.88" L (9.8mm x 200mm) - 200W - 55V | HET5520098200 | 200 mm (7.88") | 9.8 mm (0.39") · 200 W · 55 V |
| 0.39" Dia x 8.66" L (9.8mm x 220mm) - 300W - 55V | HET5530098220 | 220 mm (8.66") | 9.8 mm (0.39") · 300 W · 55 V |
| End Seal Block Tube Heater Element | HET22030010330HPFS | 330 mm | 10mm · 220 V · 300 W |
| Flat Heater Element 0.82" W x 6.50" L x 0.14" H | FHE082650014 | 0.82" W × 6.50" L × 0.14" H |
Related parts
Temperature control
Thermocouple 0.197" (5mm) Dia, 1.181" (30mm) Length, 78.740" (2000mm) · Thermocouple 0.157" (4mm) Dia, 1.181" (30mm) Length, 11.811" (300mm) · Thermocouple 0.157" (4mm) Dia, 1.181" (30mm) Length, 5.906" (150mm) · Thermocouple 0.157" (4mm) Dia, 1.181" (30mm) Length, 13.780" (350mm) · AISET Temperature Controller · Omron Temperature Controller · Sinny Temperature Controller
Seal blocks
Questions and answers
It is a replacement part for Bags Etc flow wrappers and packaging machines. Send us the machine model and serial number — we confirm the fit before you order. Contact form · +1 (833) 722-3456.
Match the diameter, length, voltage and wattage of the element you are replacing. If the markings are gone, send us the machine model and a photo of the element and we will identify it.
Availability is shown above the Add to cart button; if a part is on backorder it says so there and we confirm the lead time by email. Orders ship from Santa Clarita, CA by UPS Ground — free on orders of $299 or more within the US.
Order online, or let us match the part
Have the machine model and serial number ready. Ships from Santa Clarita, CA — UPS Ground is free on orders of $299 or more (US).
